Basic Info
Model No.: Intelligent Single Pendulum Handheld Welding Head FWH20-S20C
Brand: Zixu
Fiber Optic Interface: QBH
Wavelength Range: 1070±20nm
Rated Power: ≤3000W
Intelligent Protection Function: Have
Collimating Focal Length: 50mm
Focus Distance: 200mm
Adjustable Range Of Light Spot: 0-8mm
Auxiliary Gas: ≥0.1-1Mpa
Effective Aperture: 10mm
Weight: 0.76KG
Additional Info
Transportation: Ocean,Express
Place of Origin: China
Payment Type: L/C,T/T,D/P,D/A,Paypal
Incoterm: FOB,DDU,CFR,Express Delivery,CIF,EXW,DAF,FAS,DES,FCA,CPT,CIP,DEQ,DDP
Product Description
| Name | Intelligent simple-pendulumhandheld weldinghead |
| Model | FWH20-S20C-V4 |
| Fiber interface | QBH |
| Wavelength scope | 1070±20nm |
| Rated power | ≤3000W |
| Collimation focal length | 50mm |
| Focus focal length | 200mm |
| Regulating scope of focal point | -10mm~+10mm |
| Regulating scope of light spot | 0~8mm |
| Auxiliary pressure | ≤1Mpa |
| Weight | 0.82Kg |
Product Categories : Accessories And Consumables > Laser Accessories
